Ellab Wireless Data Logger
The TrackSense® wireless data loggers are the most complete validation solution available today. With a wide range of measuring parameters, Ellab’s data loggers are ideal for most applications.
-
Standard Data Logger Battery...
+ Battery life greatly depends on the application and logger use profile. Extensive ramping and duration at higher temperatures can reduce the average lifetime of the battery. The data logger battery incorporates the latest battery technology, which results in 2,000 hours of operation at 10 seconds sample rate at 121 °C.
-
TrackSense® Pro Mini Data L...
The TrackSense® Pro Mini data logger with an integrated Rigid Temperature Sensor has a temperature range of 0 to +140 °C with an unmatched accuracy of ± 0.05 °C (in range 0 to +140 °C). It is ideal for measuring inside packaging and due to its temperature range the data logger is ideal for sterilization applications.
-
TrackSense Pro Micro Data Lo...
The TrackSense® Pro Micro data logger with an integrated Rigid Temperature Sensor has a temperature range of -20 to +140°C with an unmatched accuracy of 0.05 °C (in range-20 to +140 °C) and has been designed for applications that depend on size.
-
TrackSense Pro Compact Wirel...
+ The Compact logger of temperature and pressure loggers with integrated sensors, are developed to fulfil the basic needs for applications where demands are few and simplicity is in focus.
+ Integrated sensor
+ Temperature and pressure sensors available
+ Temperature range: -30 to +140°C
+ Pressure range: 10mBar to 6 Bar ABS
Use the TrackSense Pro Compact data logger with:
+ Multi Reader Station for easy readings
+ ValSuite Software for analyzing and reporting
Key Features and Benefits
+ 21 CFR Part 11 Compliant
+ User-friendly validation software
+ Usable with E-Val Pro thermocouple system
+ For simple and continuous processes -
TrackSense Frigo Wireless Da...
+ For ultra-cold applications
+ Integrated Sensor
+ Large battery for extended time periods
+ LED light option
+ Temperature range from: -90°C to +85°C
Use the TrackSense Frigo data logger with:
+ Multi Reader Station for easy readings
+ ValSuite Software for analyzing and reporting -
TrackSense Lab Wireless Data...
+ The Quad Flexible Temperature Sensor with four temperature channels, has a temperature range of -30 to +100 °C with an accuracy of ± 0.1 °C. It can be used for various applications within the pharmaceutical and medical industries, for eg. washer disinfectors.
-
TrackSense Lab Wireless Data...
+ The Rigid Temperature Sensor with round tip, has a temperature range of -30 to +100 °C with an accuracy of ± 0.1 °C. It is ideal for pharmaceutical applications such as stability studies. The data loggers are equipped with an LED and have various alarm functions.
-
TrackSense Lab Wireless Data...
+ The Internal Temperature Sensor has a temperature range of -30 to +100 °C with an accuracy of ± 0.1 °C. It is ideal for pharmaceutical and medical applications such as cold storage rooms and stability chambers. The data loggers are equipped with an LED and have various alarm functions.
-
TrackSense LyoPro Wireless D...
The LyoPro is a specially designed data logger for complete batch control and validation of the freeze drying processes. The tiny data logger fits perfectly within any lyophilization setup, as the various LoggerNests allow the device to match the size of any vial.
LyoPro comes fitted with an 0.55 x 0.95 mm thermocouple sensor that ensures next to no impact on the sample during measurements, thereby providing highly valid data.
Data integrity is at its finest with TrackSense LyoPro. The internal data logger memory constantly stores every sample, allowing the ValSuite software to provide a complete picture of the process, without you ever having to worry about gaps in data.
-
TrackSense Pro Wireless Data...
The TrackSense Pro 3rd Generation data loggers with interchangeable sensors, are a durable, smart, accurate and highly flexible system used for measuring temperature, pressure, humidity, conductivity, CO2, vacuum and steam penetration.
The TrackSense Pro wireless data logger solution is ultimately configured for the user, by combining the appropriate logger with the selected interchangeable sensor.
-
LyoPro Wireless Data Logger ...
All the Measuring Points You’ll Need
Covering your entire freezer dryer with the required measurements points is easily achievable with TrackSense LyoPro. If needed, multiple access points can be connected, providing coverage for larger areas. While on a wireless live connection, up to 100 data loggers can be run simultaneously in a single study – ensuring that you will never have to split-up your studies. -
Ellab TrackSense Pro Wireles...
The TrackSense® wireless data loggers are the most complete validation solution available today. With a wide range of measuring parameters, Ellab’s data loggers are ideal for most applications.
TrackSense® Pro – Wireless Data Logger
- Interchangeable sensor option
- Many types of sensors availble
- Various parameters available
- Real-time data option
- Temperature range from -50 to +150°C
-
STC-ACS Thermocouple Sensor
The STC-ACS type T thermocouple sensor has a high measuring temperatures range of -67 to +400 °C, with an accuracy of ±0.5 °C, and a USB plug for saving calibration constants. The STC-ACS thermocouple sensor is designed for high temperature applications (e.g. dry heat sterilization and oven validation) within the pharmaceutical industry. The STC-ACS sensor works in combination with the Thermal Validation System E-Val™ Pro.
-
Ellab EvalPro Wired Thermoco...
The E-Val Pro thermocouple system for thermal validation is immensely easy to handle within controlled environments due to its compact size and light weight. The thermocouple system complies with FDA regulations as well and GAMP guidelines and is designed to be the ideal solution for any thermal validation process.
The secure and password protected module can handle up to 40 thermocouples and the large internal memory is capable of holding up to 10 studies at a time. The wired thermocouple system has a built-in 8-hour battery and can be used as a stand-alone unit or be connected to a PC via LAN/USB.
The E-Val Pro is equipped with interchangeable sensor arrays, which can easily be removed for service and calibration. With 4 and 12-channel arrays available, the E-Val Pro can handle all thermocouple types as well as analog and digital inputs.
-
E-val Pro Probe SSA-TF Therm...
The SSA-TF thermocouple sensor has a temperature range of -50 to +135 °C, with an unmatched accuracy of < 0.2 °C (calibrated ± 0.05 °C) , and a USB plug that saves calibration constants. The thermocouple is used with the Thermal Validation System, E-Val™ Pro, and is especially ideal for food applications and sterilization within pharmaceutical applications.
-
Eval Pro Probe SSA-TS Thermo...
- The SSA-TS type T thermocouple sensor has a temperature range of -20 to +135 °C, with an unmatched accuracy of < 0.2 °C (calibrated ± 0.05 °C), and a USB plug that saves calibration constants.
- The SSA-TS thermocouple sensor is especially ideal for food applications involving retort sterilization and pasteurization. The SSA-TS functions with the Thermal Validation System E-Val™ Pro.
-
Ellab Temperature and Pressu...
+ Monitoring your autoclave or retort in real-time has never been so easy. This flexible solution monitors temperature or pressure with indicator and recorder options. The ETI devices clearly display and document processes to provide quick and useful overviews.
-
Autoclave Qualification Proc...
Qualifying Your Autoclave
To ensure that your process continues to provide safe and sterile results, your autoclave must comply with established standards and norms (EN 285 and ISO 17665)
The requirements for testing your autoclave depends on the country. In Europe, the standardized cycles are 121 °C for 15 minutes or 134 °C for 3 minutes.
-
The Steam Sterilization Proc...
Steam Sterilization
Nothing is more important than patient safety!
Validated and controlled manufacturing processes are necessary to ensure that sterility requirements are reached for all products and containers during steam sterilization. View our recommended solutions and learn more about the process and equipment requirements for autoclaves/steam sterilizers.
